Vehicle Side Door Strength and Opening/Closing Durability Test System

본문

▪️ A test system that applies load to a vehicle side door using a standardized loading device to measure deformation and strength of the door and vehicle frame.
▪️ Evaluates the durability of door-related components by simulating realistic opening and closing conditions using an electric rotary actuator.
▪️ Video
▶

▪️ Control Channel : 2 channel (1 for side door strength, 1 for side door durability)

▪️ Control Modes : Displacement / Force control, Angle control

▪️ Side Door Strength Actuator Specifications : Stroke ±300mm, Load ±110kN

▪️ Opening/Closing Durability Actuator Specifications: Angle ±90°, Torque ±318 N·m
